Conductive Powder Coating
Whats/App:+86138 1621 7984
web: std-coatings.com
Product Overview
Conductive Powder Coating is engineered to provide reliable electrical conductivity while maintaining durable surface protection. You can use this coating where static dissipation, grounding performance, or electromagnetic shielding is required without compromising mechanical strength or corrosion resistance. Formulated with conductive fillers and stable resin systems, it delivers consistent conductivity and uniform film formation across complex substrates. It is suitable for metal components used in construction, electronics, transportation, industrial equipment, and automated OEM production lines.
Application
You can apply this conductive powder coating across a wide range of industries and end-use products:
Construction and Architecture
Balconies and railing systems
Curtain wall structures
Aluminum windows and door frames
Architectural metal panels
Grounding-required façade components
Home Appliances and Electronics
Electrical panels
Equipment frames
Metal enclosures
Control cabinets
Server racks and housings
Automotive and Transportation
Wheels and metal trims
Undercarriage metal parts
Battery housings
Charging station enclosures
Transport equipment casings
Industrial Equipment
Machinery housings
Protective enclosures
Piping systems
Metal tools and cabinets
Conveyor system components
OEM Production Lines
Automated bulk-coated components
Custom metal parts requiring conductive surfaces
High-volume fabricated assemblies
Parameters
| Item | Specification Range |
|---|---|
| Resin Type | Epoxy / Polyester / Hybrid System |
| Surface Finish | Matte to Semi-Gloss |
| Film Thickness | 60–120 μm |
| Surface Resistivity | 10³–10⁶ Ω (depending on formulation) |
| Adhesion | Class 0 (ISO 2409) |
| Impact Resistance | ≥ 50 kg·cm (ISO 6272) |
| Salt Spray Resistance | ≥ 500 hours (ISO 9227) |
| Curing Condition | 180–200°C, 10–20 minutes |
| Application Method | Electrostatic Spray |
| Substrate | Steel, Galvanized Steel, Aluminum |
Features
Stable and controlled electrical conductivity
Excellent adhesion to metal substrates
Reliable corrosion resistance performance
Uniform coating thickness and smooth finish
Compatible with automated electrostatic spray systems
Customizable conductivity levels based on application needs
Environmentally friendly solvent-free formulation
