TPET1205 1W 3KVDC Isolated Single Output SMD DC/DC Converters
TPET1205 1W 3KVDC Isolated 12Vin 5Vout
Single Output SMD DC/DC Converters
Miniature surface mounted DC/DC Converters are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required. these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.
Part Number Nominal Input Voltage Output Voltage Output Current (Max./Min) Efficiency
V V mA %
TPET0303 3.3 3.3 303/30.3
72
TPET0305 3.3 5 201/20.1
77
TPET0309 3.3 9 111/11.1
77
TPET0312 3.3 12 83/8.3
77
TPET0315 3.3 15 67/6.7
77
TPET0503 5 3.3 303/30.3
74
TPET0505 5 5 200/20
69
TPET0509 5 9 111/11.1
75
TPET0512 5 12 84/8.4
78
TPET0515 5 15 66/6.6
78
TPET1203 12 3.3 303/30.3 74
TPET1205 12 5 200/20
67
TPET1209 12 9 111/11.1
73
TPET1212 12 12 83/8.3
74
TPET1215 12 15 66/6.6
75
TPET1505 15 5 201/20.1
77
TPET1515 15 15 66/6.6
75
TPET2403 24 3.3 303/30.3 74
TPET2405 24 5 200/20
67
TPET2409 24 9 111/11.1
73
TPET2412 24 12 83/8.3
74
TPET2415 24 15 66/6.6
75
Add suffix “P” for continuous short circuit protection, for example TPET0505P. Add suffix “X” has not 5,10,12 pin, for example TPET0505X.
