Qinsun Xenotest 220
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
ISO 105-B02: Lightfastness testing for colored textiles.
AATCC TM16 (Option 3): Accelerated weathering for textiles under controlled conditions.
Marks & Spencer C9/C9A: Retail-specific durability protocols for apparel and home textiles.
Product Advantages
Unmatched Capacity:
Tests38 samples simultaneously, doubling the throughput of the 150 S+ model within the same footprint.
Optimized for high-volume testing without compromising precision.
Cost Efficiency:
Air-cooled designreduces energy consumption by 30% compared to water-cooled alternatives.
60-liter integrated water tankminimizes refill frequency for ultrasonic humidification.
Precision Control:
Direct adjustment of irradiance (300–400 nm), black label temperature, chamber humidity, and airflow.
Dual temperature control(up to 100°C) for black label and chamber, managed via fan-assisted differential regulation.
User-Centric Design:
220+ Model: Color touchscreen interface with multi-language support (10+ languages) and 10 programmable test presets.
Advanced Diagnostics: Real-time error alerts and internal data logging via storage chip.
Compliance & Versatility:
Preconfigured for ISO and AATCC standards, with customizable end-of-test triggers (sunlight exposure, runtime, or illumination dose).
Product Features
Illumination System:
2200W air-cooled xenon lamp tube for stable UV-A to visible light output.
Long-life filter technologyensures consistent spectral distribution (300–400 nm) over 1.500+ hours.
Sample Handling:
XENONSENSIV® Sample Rack: Holds 19 containers (38 textile samples) with integrated sensors for irradiance (W/m²) and black label temperature (°C) monitoring.
Climate Control:
Ultrasonic humidification with automatic water replenishment.
Relative humidity range: 10%–70% RH (non-condensing).
Connectivity:
Ethernet & RS232 interfacesfor data export.
XenoTouch Attachments: Remote monitoring, alerts, and cloud integration (Optional 1/2/3).
Safety & Durability:
UV-blocking observation window for safe sample inspection.
Robust construction with corrosion-resistant materials for industrial environments.
Technical Parameters
| Specification | Details |
|---|---|
| Lamp Type | 2200W air-cooled xenon arc |
| Exposure Area | 310 cm² (48 in²) |
| Irradiance Control | 300–400 nm, adjustable via touchscreen (220+) |
| Temperature Range | Chamber: 30–65°C (86–149°F) / Dual: 30–100°C |
| Humidity Range | 10%–70% RH (non-condensing) |
| Power Supply | 230V, 50/60Hz, 25A |
| Dimensions (W×D×H) | 900 × 750 × 1.800 mm |
| Weight | 320 kg (705 lbs) |
