Veslic Multi-Functional Material Tester for Advanced Quality Control-QINSUN

Standard

ISO 13934-1(Tensile Properties of Fabrics)

ASTM D624(Tear Strength of Rubber and Elastomers)

AATCC 135(Dimensional Changes in Textiles After Home Laundering)

Product Advantages

All-in-One Testing

Combines tensile, tear, abrasion, and dimensional stability testing in a single platform, reducing equipment costs by 40%.

Precision Engineering

High-resolution load cell (±0.01 N accuracy) and 360° sample grips capture micro-deformations and weak points.

Smart Automation

AI-driven test protocols adjust speed, load, and cycles in real time, optimizing results for 50+ material types.

User-Centric Design

15.6-inch touchscreen interface with multilingual support (English, French, German, Chinese) and one-touch calibration.

Modular Expandability

Optional add-ons for colorfastness, pilling, and UV resistance testing future-proof your lab.

Product Features

Testing Modes

Tensile Strength: 0–5.000 N load capacity for fabrics, rubber, and composites.

Tear Resistance: Trapezoidal and tongue-shaped specimen grips for ASTM/ISO compliance.

Abrasion Simulation: Dual-motion system (rotary/reciprocating) with adjustable pressure (0.5–50 N).

Shrinkage Analysis: Automated dimensional measurement post-laundering (AATCC 135).

Real-Time Analytics

4K camera system (120 FPS) with AI-powered defect detection and stress mapping.

Data Ecosystem

Cloud-connected software stores 100.000+ test results, predicts material lifespan, and integrates with ERP/MES systems.

Safety & Sustainability

Low-energy mode (60% power reduction), self-cleaning chamber, and CE/UL/RoHS certification.

Technical Parameters

Parameter	Specification
Load Cell Capacity	0–5.000 N (±0.01 N accuracy)
Speed Range	1–500 mm/min (tensile) / 1–200 RPM (abrasion)
Sample Grip Options	Pneumatic, hydraulic, and manual clamps for 5–50 mm widths
Dimensions (L×W×H)	1.200×900×1.800 mm
Weight	450 kg
Operating Environment	5–40°C, ≤85% RH (non-condensing)
Power Supply	220V/110V AC, 50/60Hz, 4.5kW

Accessories Included

Testing Kits:

10× tensile grips (flat/rounded), 5× tear resistance blades (ASTM/ISO).

2× abrasion heads (felt/sandpaper discs).

Calibration Tools:

Load cell verifier, speedometer, and NIST-traceable certificate.

Sample Fixtures:

Pneumatic clamps for flat/curved specimens, vacuum chuck for thin films.

Software Suite:

AI analytics platform with predictive maintenance, ERP integration, and 8-language report generator.

Safety Bundle:

Emergency stop, acoustic enclosure, and fume extraction port.

Ideal For:

Textile manufacturers (apparel, upholstery, technical fabrics)

Automotive OEMs (interior trim, seat belt, and airbag durability)

Medical device makers (biocompatible polymer testing)

Research universities (multidisciplinary material science)
