High-efficiency Filter Test Bench
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
This test bench is suitable for performance evaluation of high-efficiency air filtration products used in cleanrooms, microelectronics, pharmaceuticals, hospitals, nuclear facilities, aerospace, biolabs, and HVAC systems.
Typical test items include HEPA filters, ULPA filters, mini-pleat filters, panel filters, and high-efficiency fan filter units (FFUs).
It is widely used in filter manufacturers, third-party laboratories, quality inspection institutes, and R&D centers requiring precise MPPS and resistance testing.
Standards
The equipment complies with or references the following standards:
EN 1822 Series, including EN1822-5 – High-efficiency air filters
ISO 29463 – High-efficiency filters and filter media
IEST-RP-CC021 – HEPA/ULPA filter testing guidelines
GB/T 6165-2008 – Testing of high-efficiency air filters
Designed based on European principles for MPPS performance testing
Features
High-precision particle counting and DEHS aerosol distribution system
Supports full MPPS efficiency, resistance, and flow curve testing
Stable airflow control with ≤2% adjustment accuracy
Compatible with various filter sizes through interchangeable fixtures
Fully enclosed test channel ensures stability and safety
Automated data output and reporting via integrated printer
Engineered for long-term industrial and laboratory operation
Technical Parameters
| Parameter | Specification |
|---|---|
| Power Supply Voltage | Single-phase AC220V ±5%, Three-phase AC380V ±5% |
| Power Consumption | Approx. 15 kW |
| Frequency | 50 Hz ±2 Hz |
| Aerosol Type | DEHS |
| Particle Size | 0.1–0.3 μm |
| Test Efficiency | H13–U17: ≥99.95%–≥99.999995% (MPPS) |
| Resistance Range | 0–1000 Pa |
| Airflow Range | 500–3500 m³/h, accuracy ≤2% |
| Sampling Flow | 28.3 L/min ±5% |
| Applicable Filter Size | Max: 630 × 630 mm, Min: 300 × 300 mm |
| Data Output | Printer |
| Equipment Dimensions | Approx. 13,000 × 3,000 × 3,000 mm (L × W × H) |
