Digital Auto Burst Strength Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Application
Digital Auto Burst Strength Tester is used to determine the bursting strength and distension at burst of woven, knitted and non woven fabrics, papers and boards by the application of hydraulic loading under a rubber diaphragm.
The intelligent control algorithm gives accurate control of the burst time. Manual or automatic mode. Windows based software could analyze the test results and print, easy to operate. Different test areas can be accommodated allowing testing to corresponding standards.
Standard Test
ASTM D3786:Textile Fabrics - Bursting Strength Test Method(Diaphragm Type)
ERT 80-4-20: European Textile Research Association Standard - Test Method for Fabric Bursting Strength
BS EN ISO 13938-1:Textiles - Bursting Properties - Part 1: Hydraulic Method for Determination of Bursting Strength and Bursting Distension
BS 3424-6-B:Methods of Test for Coated Fabrics - Part 6: Bursting Strength
ISO 3303-B:Packaging - Sacks - Testing of Coated Flexible Intermediate Bulk Containers - Bursting Test
ISO 2758:Paper and Board - Determination of Bursting Strength
ISO 3303.2:Packaging - Sacks - Testing of Uncoated Woven Polypropylene Sacks - Bursting Test
ISO 3689:Metallic Materials - Rockwell Hardness Test - Test Method
JIS L1018/L1093:Textiles - Testing Methods for Woven Fabrics/Knitted Fabrics
IWS TM170: International Wool Secretariat Standard Test Method for Bursting Strength of Wool Fabrics
Feature
1. Several different specimen sizes can be accommodated allowing testing to most corresponding standards, test areas up to 100cm can be accommodated for GB;
2. Pneumatic clamping, firm and uniform of grip, can be used for various materials;
3. PC online communication, statistical analysis, with test reports printed;
4. Output multiple indexes: bursting pressure, bursting strength, diaphragm pressure, distension height, burst time; convenient to master the sample property for quality control personnel.
Parameters
| Technical Parameters | Specifications |
|---|---|
| Measuring Range (Bursting Pressure) | 1%～100%,10–6000kPa; minimum value: 0.002MPa |
| Diaphragm Specification | outside diameter of Φ80mm, thickness of 0.9±0.1mm |
| Clamping Device (Diameter) | Φ112.8mm±0.2mm(100cm), Φ79.8±0.2mm(50cm), Φ35.7±0.2mm(10cm), Φ31.5±0.2mm(7.5cm), Φ30.5±0.2mm(7.3cm), Φ30±0.2mm |
| Max Bursting Elongation | 0±0.02mm |
| Max Bursting Time | 99.9±0.1s |
| Rate of Increase (Pressure) | 100-500ml/min, manual or automatic adjustment |
| Output Mode | display and print for output, real-time graphic, online communication |
| Operating Mode | Manual or automatic |
| Hydraulic Liquid | glycerin of 85%, distilled water of 15% |
| Power Supply | AC220V, 50Hz, 2000W |
| Dimensions (L×W×H) | 750×500×950mm(L×W×H) |
| Weight | 160kg |
