Fiber Oil Extractor
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Fiber Oil Extractor, also known as the Rapid Grease Extraction Apparatus, is designed for rapid and accurate determination of grease or finish content in wool, synthetic fibers, yarns, or fabrics. Using solvent percolation and evaporation, the apparatus delivers fast results suitable for quality control and processing purposes in textile production. Multiple extraction units can operate simultaneously for higher throughput.
Application
This apparatus is widely used in:
Wool processing plants to determine grease content of wool tops and combed slivers.
Synthetic fiber production lines for monitoring finishing oil content.
Yarn production quality control.
Textile laboratories for research, development, and fiber treatment evaluation.
Educational institutions for practical training in fiber analysis.
Standards
Edana Method ERT 155 – Determination of grease or finish content in wool and synthetic fibers.
Features
(1) Multi-unit design allows 1, 2, or 3 extraction units for simultaneous testing.
(2) Simple percolation principle ensures rapid and reliable extraction of oil content.
(3) Temperature-controlled hot-plate provides consistent solvent evaporation.
(4) Adjustable plunger and weight system ensures uniform packing and pressure in the extraction tube.
(5) Suitable for wool, synthetic fibers, and yarn; fabric can be tested after disintegration into yarn.
(6) Pedestal, extraction tube, plunger, cotton plug, tray, and hot-plate designed for durability and ease of operation.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | Ambient – 250°C |
| Temperature Accuracy | ±1°C |
| Timing Range | 1–9999 min |
| Number of Specimens | 3 |
| Solvent Types | Petroleum ether, ether, dichloromethane |
| Loading Mode | Weighted plunger system |
| Extraction Tube Size | Standard tube for fiber, yarn, or sliver |
| Outer Dimensions | 170×170×380 mm (L×W×H) |
| Weight | 4.4 kg (9.7 lb) |
| Power Supply | AC 220V, 720W |
| Power Dissipation | ≥175 W |
