Automobile Headrest Strength Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Automobile Headrest Strength Tester is designed to evaluate the ultimate strength and durability of automotive headrest assemblies in accordance with FMVSS 202 requirements.
Technical Specifications
| Feature | Specification |
|---|---|
| Test Standard | FMVSS 202 |
| Test Purpose | Determine ultimate strength of up to three headrest assemblies |
| Test Capacity | 3 headrest stations (concurrent testing) |
| Configuration Options | Hydraulic or Electric |
| Control System | PC-based Control and Data Acquisition (floor-standing console) |
| Power Supply | 115 V.A.C. (other voltages available) |
| Table Construction | 1-inch (25.4 mm) thick ground steel plate |
| Hole Array | 4-inch (101.6 mm) grid with ½”-13 threaded holes |
| Movement Adjustments | Adjustable height and in/out movement relative to “H” point pivots |
| H-Point Alignment | Center station adjustable vertically and horizontally |
| Lateral Adjustment | Outer stations movable for occupant spacing |
| Locking Mechanism | All set-up movements lockable to prevent displacement |
| Control Valves (Hydraulic model) | Double-solenoid directional valves with compensated regulators |
| Table Lift | Electric motor-driven |
| Operation Speed | Controlled slow movement for real-time observation |
| Data Acquisition | Real-time recording, graphical plotting, and data export |
| Software Interface | Standard pull-down menus for plotting and analysis |
| Data Output | PC file saving, downloading, and color inkjet printout |
