Hydraulic Oil Filtration and Dehydration Unit

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Hydraulic Oil Filtration and Dehydration Unit is an integrated oil purification system that combines filtration, dehydration, degassing, and demulsification functions. You can use this equipment to remove solid contaminants, water, and gases from hydraulic and lubrication system oils during operation. By combining multi-stage precision filtration with physical dehydration technology, the unit effectively improves oil cleanliness, extends the service life of hydraulic components and lubricated parts, and ensures reliable and stable system performance.

Standards

You can operate this unit in compliance with the following standards:

(1) GB/T 18854-2015 – Hydraulic transmission: Determination of solid particle contamination levels in hydraulic oil;

(2) GB/T 14039-2002 – Hydraulic transmission: Oil contamination control and monitoring;

(3) GB/T 4207-2012 – Determination of water content in mineral-based lubricating oils;

(4) ISO 4406:2017 – Hydraulic fluid power: Coding of solid particle contamination levels;

(5) ISO 4407:2002 – Hydraulic fluid power: Particle counting method for contamination measurement;

(6) ISO 9110:1990 – Hydraulic fluid power: Filter performance test methods.

Parameters

ParameterUnitValue
Rated Flow L/min 40 / 100 / 150
Rated Pressure MPa 0.6
Initial Pressure Loss MPa ≤ 0.2
Coarse Filter Precision μm 100
First-Stage Filter Precision μm 25 / 40
Second-Stage Filter Precision μm 3 / 5 / 10
Motor Power kW 1.1 + 0.75 / 2.2 + 1.1 / 4 + 1.1
Power Supply V AC 380
