Carton drop tester，ASTM D5276 drop tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Carton Drop Tester is designed to simulate the impact experienced by packaging during transportation, handling, and loading/unloading. It evaluates the impact strength of packages, the durability of materials, and the rationality of packaging design by performing controlled free-fall drops.
Applications
This tester is widely used in the packaging, logistics, electronics, food, pharmaceutical, and e-commerce industries. It is suitable for manufacturers of corrugated cartons, boxes, and transport packaging to ensure product protection and optimize packaging design.
Standards
The Carton Drop Tester meets the following international and national standards:
ISO 2248 – Packaging — Transport packages — Vertical impact test by dropping
GB/T 4857-5 – Packaging — Transport packages — Vertical impact test by dropping
ASTM D5276 – Standard test method for drop test of loaded containers by free fall
ISTA 1A, 2A, 3A – International Safe Transit Association protocols
ASTM 4619 – Standard test methods for packages
IEC 60068-2-31 – Environmental testing — Drop test
JIS Z0202 – Japanese Industrial Standard for package drop testing
EN 438-2.21 – High-pressure decorative laminates — Determination of impact resistance
Advantages
Accurate and repeatable testing with consistent results
Simulates real-world handling and shipping conditions
Identifies weak points in packaging design
Ensures adequate product protection
Supports compliance with international standards
Provides data for optimizing packaging strength and cost
Features
Adjustable drop height from 300 mm to 1500 mm
Free, reliable, and precise release mechanism
Capable of surface, edge, and corner drop tests
Rigid impact surface to ensure consistent test conditions
Motorized or pneumatic lifting mechanism
Digital controls and touch-screen interfaces (optional)
Safety features to protect operators and equipment
Sturdy frame supporting packages up to 70 kg
Technical Parameters
| Parameter | Specification |
|---|---|
| Drop height | 300–1500 mm (adjustable) |
| Maximum sample weight | 70 kg |
| Maximum sample size | 800 × 800 × 800 mm |
| Impact panel size | 1700 × 1200 × 14 mm |
| Motor power | 1.85 kW |
| Overall dimensions (L × W × H) | 1700 × 1200 × 2350 mm |
| Net weight | ~600 kg |
| Power supply | AC 380 V, 50 Hz |
| Control | Motorized and pneumatic lifting, wired remote control |
| Drop test modes | Surface, edge, corner |
Accessories
Adjustable sample holders
Remote control for motorized operation
Calibration reference standards (optional)
Safety guards and operator protection devices
Test Procedures
1. Preparatory Work
Inspect Equipment: Check all components of the testing machine for integrity. Verify that lifting mechanisms, release mechanisms, locking devices, and other parts show no signs of looseness, damage, or abnormal noises. Simultaneously inspect the electrical system for proper function, ensuring wires are undamaged and plugs are securely connected.
Select Impact Surface: Choose an appropriate impact surface based on testing standards and the characteristics of the test item. Install it securely, ensuring the surface is level and firmly fixed.
Position Test Item:
Carefully place the test item on the designated area of the test platform. For irregularly shaped or easily displaced items, secure them using appropriate fixtures or restraints to prevent shifting during lifting and drop cycles.
2. Parameter Setup
Set Drop Height:
Precisely configure the drop height according to test requirements using the machine's height adjustment mechanism or control panel. Some test machines allow height adjustment via rotary knobs, button operations, or touchscreen inputs. Verify the height value is accurate after setting.
Select drop method: Choose the appropriate drop method based on requirements, such as face drop, edge drop, or corner drop. Different drop methods may require adjusting the orientation of the test item on the platform or using different fixtures.
3. Conducting the Test
Lift the platform: Activate the lifting mechanism to smoothly raise the test platform to the preset drop height. Closely monitor the platform's operation during ascent to ensure steady movement without jamming or shaking.
Execute the drop: Once the platform reaches the set height and stabilizes, activate the release mechanism to allow the test item to freely fall onto the impact surface. Observe the test item's drop state during release for any abnormalities.
4. Post-Test Procedures
Inspect the Item: After completing the drop test, carefully remove the test item and inspect its appearance for damage such as cracks, deformation, or scratches. Additionally, for items with functional requirements, conduct functional testing to verify proper operation.
Record Data: Document all parameters from the test process in detail, including drop height, drop method, model and specifications of the test item, and post-test inspection results. This documentation facilitates subsequent analysis and evaluation.
