Ford Automotive wire flexibility testing machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Versatile Angle Adjustment: Swings up to 180° bi-directionally or any user-defined angle, accommodating sharp-bend (e.g., R3.75) and gradual-curve testing scenarios.
Triple-Station Efficiency: Three independent test channels enable parallel testing of different wire specifications, tripling throughput compared to single-station machines.
Precision Fatigue Analysis: ±1 cycle/min speed control and 6-digit counter ensure accurate life-cycle prediction, critical for validating warranty periods.
Adaptive Fixture System: Interchangeable R-angle fixtures (R3.75. R7.2. R9.6. etc.) cater to wires from thin gauge (0.5mm²) to heavy-duty cables, eliminating costly retooling.
Safety & Data Integrity: Automatic stop-on-break function prevents post-failure damage, while memory retention resumes testing after power interruptions.
Technical Parameters
| Parameter | Specification |
|---|---|
| Swing Angle Range | 0°–180° (CW/CCW), adjustable in 1° increments |
| Operating Speed | 10–60 cycles/min (±1 cycle tolerance) |
| Cycle Counter | 1–999.999 counts (presettable with pause/resume) |
| Test Stations | 3 independent channels with quick-release fixtures |
| Applied Loads | 2.5N, 3.75N, 5N, 7.5N (interchangeable weights) |
| Fixture R-Angle Options | R3.75. R7.2. R9.6 (customizable per AWG/mm²) |
| Test Voltage | 24V DC (built-in supply) |
| Power Input | AC 220V ±10%, 50/60Hz (switchable to DC 24V/5A) |
| Machine Dimensions (W×D×H) | 600 × 450 × 750 mm |
| Net Weight | 50 kg |
