Automatic Double Plate Thermal Conductivity Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
This thermal conductivity meter mainly tests homogeneous plate materials such as plastics, glue, glass, fiber, benzene board, extruded board, foam concrete, hollow glass, wooden boards, various insulation materials, etc. It can also measure granular materials and bulk materials. soft materials and other materials.
Standards：
GB/T10295-2008
ASTM E1530、ASTM C518-04
ISO 8301
DIN EN 12664
Main technical parameters：
| Item | Parameters |
| Thermal conductivity range | 0.0001 ~ 1W / m-k, can be measured accurately to 0.1mw / m-k |
| 0.001 ~ 300W / m-k. computer automatically switch range | |
| Measuring accuracy | 1% |
| Specimen size | 50*50 ~ 150*150, 150*150 ~ 300*300(mm) optional (standard configuration), the thickness is not greater than 50mm. |
| Sample state | Can test solid material, powder material |
| Measuring time | 15~20 min |
| Hot surface temperature range | RT~ 99.9 ºC (standard configuration), RT ~ 299.9 ºC, RT ~ 499.9 ºC optional |
| Hot surface temperature control | Plate heater, bi-directional SCR control, temperature control accuracy 0.1ºC |
| Cold surface temperature range | 0 ~ 99.9 ºC (standard configuration), -10 ~ 99.9 ºC, according to user requirements to determine the lower temperature |
| Cold surface temperature control | Water-cooled to ensure the stability of the cold surface temperature (precision thermostatic water tank, temperature adjustable), |
| temperature control accuracy of 0.1 ºC | |
| Specimen clamping pressure range | 0 ~ 1000N, resolution 0.1N |
| Sample thickness range | Measure automatically, 0 ~ 50mm, resolution 1um |
| Heat flow meter | Imported original heat flow meter |
| Data storage | Computerized automatic testing and storage printing and storage of experimental data |
| Machine dimension | (L*W*H)550*450*1500mm |
| Machine weight | Approx. 100KG |
| Water bath dimension | (L*W*H)300*350*530mm |
| Water bath weight | Approx. 35KG |
| Power | 1∮ AC 220V 1KW |
| Standards | GB/T10295-2008, ASTM E1530, ASTM C518-04, ISO 8301, DIN EN 12664 |
