Rotary reciprocating friction and wear tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Applications
You can use this tester to:
Evaluate the tribological performance of material surfaces and coatings
Test wear resistance and friction coefficients of friction pairs, including metals, polymers, and ceramics
Monitor friction force, temperature, and other parameters in real time
Support material research, quality control, and production testing
Standards
ASTM G99 – Standard Test Method for Wear Testing
ASTM G133 – High-Temperature Friction and Wear Test Method
ISO 20808 – Solid Material Friction and Wear Test
GB/T 3147 – Determination of Friction Material Wear Performance
Technical Specifications
| Parameter | Range / Specification |
|---|---|
| Maximum Test Force | 1000 N |
| Maximum Speed | 2000 rpm |
| Maximum Frequency | 200 Hz |
| Maximum Reciprocating Friction Force | 100 N |
| Maximum Rotational Torque | 4.7 Nm |
| Reciprocating Stroke Range | ±6 mm |
| Reciprocating Friction Modes | Ball-on-disk, Pin-on-disk, Cylinder-on-disk |
| Rotational Friction Modes | Ball-on-disk, Pin-on-disk, End-face |
| Temperature Range | Room temperature – 600℃ |
| Notes | Optional micro-force module, ring-block module available |
