Ross Flex Tester

Get a quote:

Web: qinsun-lab.com

Email:info@qinsun-lab。com

The Ross Flex Tester evaluates the zigzag resistance and flex fatigue performance of sole materials. Pre-cut sole test pieces are mounted on the tester and subjected to repeated 90° zigzag bending. The notch growth rate is measured after testing to quantify the flex cracking resistance of the material, providing an objective assessment of sole durability.

Standards

(1) GB/T 2099-2007 — Footwear Test Methods

(2) ASTM D1052 — Standard Test Method for Flexing Endurance of Sole Materials

(3) ISO 5423 — Rubber and Plastics — Determination of Flex Cracking

(4) SATRA TM60 — Ross Flex Test

(5) HG/T 2411 / HB-T2411 — Footwear Sole Flexing Test Methods

(6) EN ISO 20344 — Footwear — Test Methods

Technical Parameters

ItemSpecification
Simultaneous measurement 12 test pieces
Bending angle 90 ± 2°
Speed 0–100 r/min (switchable)
Controller LED-SLD806 integrated display control
Hole punch diameter 2.5 mm
Test mode Automatic stop after preset cycles/time
Fixture features Can test sole strips and individual pieces simultaneously
Zigzag shaft diameter 10 mm
Sample method Sole test piece
Sample size 152 × 25 mm
Power supply AC 220V, 10A
