Vacuum Cleaner Air Performance Testing Equipment
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
Vacuum Cleaner Air Performance Testing Equipment is a professional testing system designed to evaluate the air performance of vacuum cleaners in accordance with international standards. You can use this equipment to accurately measure and analyze key performance parameters such as voltage, current, input power, power factor, airflow, vacuum pressure, suction power, and overall efficiency. The system integrates European and American standard testing modes, making it suitable for global product verification, R&D validation, and compliance testing.
Standards
-
IEC 60312-1: Vacuum cleaners for household use – Methods for measuring the performance – Part 1: Dry vacuum cleaners
-
IEC 62885-2: Surface cleaning appliances – Part 2: Dry vacuum cleaners for household or similar use – Methods for measuring the performance
-
ASTM F431-21: Standard Test Method for Measuring the Air Performance Characteristics of Vacuum Cleaners
-
ASTM F558-17: Standard Test Method for Measuring Air Performance Characteristics of Upright, Canister, Handheld, Stick, and Robotic Vacuum Cleaners
Technical Parameters
| Item | Specification |
|---|---|
| Test Stations | Single station (Euro standard / US standard) |
| Pressure Chamber Dimensions | Euro standard: 500×500×500 mm; US standard: 457.2×457.2×254 mm |
| Test Modes | Euro standard, US standard |
| Drive Motor | Servo motor |
| Flow Meter | Range: 0.5–5 m³/min; Accuracy: ±0.05% / 0.075% |
| Vacuum Gauge | Range: -50–0 Kpa; Accuracy: ±0.075% / ±0.05% |
| Orifice Plate Sizes (Euro & US standard) | 63.5, 57.2, 50.8, 44.5, 38.1, 34.9, 31.7, 28.6, 25.4, 22.2, 19.0, 15.8, 12.7, 9.5, 6.3 mm |
| Power Supply & Current Detection | AC: 0–250V; DC: 0–60V; Current detection range: 0–30A |
| Equipment Power | 220V, 2.5KW |
| Equipment Dimensions | 1850×1150×1750 mm |
