ISO 1518 Paint Surface Scratch Resistance Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
ISO 1518 Paint Surface Scratch Resistance Tester is a laboratory testing device used to evaluate the scratch resistance of paint films and coated surfaces. It is suitable for automotive surface coatings, metallic paints, coil coatings, ink coatings, and other material surfaces. By applying pressure through a controlled scratch needle, it creates repeatable scratches on the sample surface to determine the coating's scratch resistance.
Application
Road/rail/marine coatings;
Textile/printing surface coatings;
Aerospace coatings and materials;
Automotive and component surface coatings;
Comprehensive material surface scratch resistance testing.
Standards
ISO 1518 Paints and varnishes – Determination of scratch resistance
ASTM D5178 Test method for determining scratch resistance of coatings using a linear scratch apparatus
ASTM D2197 Test method for determining abrasion resistance of organic coatings
GB/T 23989‑2009 – Determination of scratch resistance of coatings
GB/T 1768-2006 – Test Method for Abrasion Resistance of Paint Films
GB/T 6739-2006 – Paints and Varnishes – Determination of Hardness of Paint Films by the Pencil Method
GB/T 9279-2007 – Paints and Varnishes – Cross-Hatch Adhesion Test
Parameters
| Item | Details |
|---|---|
| Input Voltage | 220V/50Hz |
| Control System | PLC + Touch Screen |
| Operation Interface | 7-inch color touch screen, Chinese/English switchable |
| Driving Method | Stepper motor drive |
| Scratching Speed | 0–25 mm/s, adjustable |
| Limited Stroke | 0–85 mm (other strokes available for free customization) |
| Test Times | 0–9999 times, presettable |
| Equipment Configuration | Automatic stop function after scratch contact (electrode device) |
| Contact Limit Angle | 18° |
| Contact Spherical Transition Size | R6 |
| Scratch Spacing | 0–50 mm, adjustable |
| Test Size | Approximately 150*100 mm range |
| Worktable | 360° rotatable |
| Scratching Pressure | Standard: 10N±0.5N, 1 piece; optional: 20N weight and 30N±0.5N scratching pressure |
| Scratching Head | R0.25±0.02 mm, other specifications optional |
| Dimensions | 380×300×180 mm (L×W×H) |
Features
PLC + touchscreen control with intuitive and user-friendly interface;
7-inch color touchscreen with Chinese/English language switching;
Stepper motor drive ensures smooth scratch motion;
Adjustable scratch pressure supports multiple test force values;
Customizable scratch needles adapt to different coating types;
Workbench rotates 360° for omnidirectional scratch testing;
Auto-stop function halts immediately upon contact, enhancing safety and accuracy;
Pre-set test cycles enable automated operation.
