Benchtop Multi-Function Friction and Wear Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
Application
The Benchtop Multi-Function Friction and Wear Tester is designed for a wide range of tribological test scenarios, including:
Friction and wear evaluation of metals, ceramics, polymers, coatings, and composite materials
Performance assessment of lubricants, greases, additives, and extreme-pressure lubricants
Scratch resistance, indentation behavior, and surface damage analysis
Fretting and linear reciprocating wear studies
Torque testing for tapping, twisting, and cutting tools
Tribological behavior analysis under high temperature, low temperature, vacuum, and corrosive environments
Supported test configurations include ball-on-disk, pin-on-disk, high-speed reciprocating motion, ring-on-block, and related modular test modes.
Standards
The tester is designed to support test methods referenced in the following standards:
ASTM G99 (Standard Test Method for Wear Testing with a Pin-on-Disk Apparatus)
ISO 20808 (Fine ceramics — Determination of friction and wear characteristics of monolithic ceramics by ball-on-disk method)
GB/T 3142 (Determination of load-carrying capacity of lubricants — Four-ball method)
SH/T 0189 (Test method for anti-wear properties of lubricating oils — Four-ball method)
Parameters
| Item | Description |
|---|---|
| Platform Structure | Rigid structural design for stable and repeatable tribological testing |
| Environmental Control | Temperature: −50 °C to 1000 °C; Humidity: 5–95 % RH; optional corrosion and other environmental chambers |
| Interchangeable Test Modules | Quickly replaceable modules including rotational, reciprocating, and ring-on-block modules |
| Dual Force Sensor System | Two sensors can be installed simultaneously; force range from mN to 3000 N |
| X-axis Platform | High-precision automated X-stage with 150 mm travel for test module positioning |
| Data Acquisition & Motion Controller | High-speed, low-noise, multi-channel controller with fast feedback and data sampling rate up to 200 kHz |
Features
Standard test configurations including ball-on-disk (pin-on-disk), high-speed reciprocating motion, and ring-on-block
Wide loading capability from mN to 3000 N covering nano to macro tribological testing
New-generation dual force sensor technology enabling seamless force range switching
Closed-loop servo loading control for high stability and repeatability
Broad temperature testing capability from −60 °C to 1000 °C
Modular design with fast and easy module replacement
Fully automated X-axis positioning platform for efficient and repeatable testing
