Stapler Blade Sharpness Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The sharpness tester for stapler blades is mainly used to assess the sharpness of blades for medical staplers, ensuring the quality of surgical instruments and the surgical outcome. Specifically, the tester simulates the process of the blades cutting materials, measures and analyzes parameters such as the force and displacement during cutting, and then determines the sharpness value of the blades. This test result not only provides important quality - control evidence for medical device manufacturers but also offers reliable reference data for medical workers when choosing surgical instruments.
Standards
YY/T 1797 - 2021： Surgical blades - Test method for sharpness and cutting performance
Features
1.Industrial-grade 7-inch capacitive touchscreen with a menu-driven interface for easy and intuitive operation.
2.Professional software design with multi-level access control for convenient laboratory management and standardized equipment use.
3.Supports remote upgrades and maintenance.
4.Equipped with a miniature printer for easy printing of test results.
Technical Parameters
| Parameter | Specification |
|---|---|
| Testing Accuracy | ±0.01N |
| Testing Speed | 0.05–600mm/min (Some models may vary, e.g., 600mm/min±30mm/min) |
| Testing Material | Complies with the 3-0 uncoated silk-like twisted strand suture specified in YY0167-2005 (or other standard testing materials) |
| Power Supply | 220V 50Hz; Overall Power Consumption: 70W (or other values) |
| External Dimensions | 400×290×275mm (or other dimensions) |
| Net Weight | 15kg (or other values) |
Accessoriess
Standard configuration: Main unit, mini printer
Optional accessories: Professional software, communication cable
