Glove thermal insulation performance tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The tester is primarily used in the following scenarios:
Evaluating thermal resistance of household and industrial gloves
Assessing materials used in automotive, kitchen, and industrial safety gloves
Supporting R&D and quality control departments for heat-protective materials
Ensuring compliance with manufacturing specifications and safety regulations
Standards
The tester complies with and supports testing according to:
BS 6526:2002 – Household Oven Gloves Specification and Test Methods
ISO 12127 – Protective Gloves for Thermal Hazards (Reference Method)
EN 407 – Protective Gloves Against Thermal Risks
ASTM F1060 – Standard Test Method for Thermal Insulation of Materials
ISO 188 – Rubber, Vulcanized or Thermoplastic – Accelerated Ageing and Heat Resistance
Parameters
| Parameter | Specification |
|---|---|
| Sample Size | Diameter 70 mm |
| Temperature Range | Room Temp +5°C to 180°C |
| Temperature Accuracy | ±0.5°C |
| Temperature Resolution | 0.1°C |
| Polyethylene Sample Mounting Plate | 120 × 120 × 25 mm |
| Mounting Plate Sensor Range | 0–260°C, ±0.1% |
| Heating Block Sensor Range | 0–260°C, ±0.1% |
| Brass Cylinder Weight | 3000 ±10 g |
| Brass Cylinder Dimensions | Small end Φ32 ±0.02 mm H20 ±0.05 mm; Large end Φ76 ±0.02 mm H74 ±0.05 mm |
| Sensor Detection Point | 2.5 mm ±0.05 mm from cylinder base |
| Cylinder Drop Speed | 25 mm/s (adjustable 1–60 mm/s) |
| Cylinder Return Speed | 25 mm/s (adjustable 1–60 mm/s) |
| Distance from Cylinder to Sample | 100 mm ±0.5 mm |
| Polyethylene Protective Plate | 200 × 250 × 15 mm |
| Protective Plate Distance to Sample Surface | 50 mm |
| Protective Plate Movement Speed | 80 mm/s |
| Time Measurement Range | 0–99999.9 s |
| Power Supply | AC 220V, 50Hz |
| Dimensions (L×W×H) | 540 × 380 × 500 mm |
| Total Weight | 40 kg |
