Textile/Leather Abrasion Resistance Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
You use this tester to evaluate the abrasion resistance of motorcycle protective clothing under impact conditions.
It is suitable for testing motorcycle jackets, pants, protective suits, reinforced fabric panels, elbow and knee protection areas, and other protective components used in motorcycle rider apparel.
Standards
The Protective Clothing Impact Abrasion Tester complies with the following standard:
(1) GB/T 24278-2019 Protective clothing for motorcycle riders
Parameters
| Item | Specification |
|---|---|
| Control System | Industrial-grade PLC |
| Operation Interface | 7-inch color touchscreen, Chinese/English |
| Operation Mode | Full touchscreen operation, programmable test settings |
| Printer | Built-in printer |
| Belt Speed | 8 m/s |
| Belt Hardness | Grit OP60 |
| Abrasion Area | 1963 mm² |
| Applied Force on Specimen | 49 N |
| Net Pressure on Specimen | 25 kPa |
| Drop Height | 50 mm |
| Specimen Holder | Diameter Φ75 mm |
| Cleaning Brush | Diameter Φ200 mm, polypropylene bristles, 0.2 mm thickness, 45 mm free length |
| Software Interface | USB interface, data reading and PC connection |
Features
You can set test parameters directly through the intelligent control system.
The tester performs automatic cyclic testing after parameter input, reducing manual intervention.
You can pause the test at any time to observe specimen abrasion by opening the safety door.
A servo drive system ensures fast response, stable speed, and no speed fluctuation during testing.
The system provides stable and repeatable test results for impact abrasion evaluation.
