Air-ventilation Aging Test Chamber
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
Designed for precise heat aging performance evaluation of electric wire, leather, plastic, rubber, cloth, plastic, paper, and various insulating heat-resistant materials. It serves as an essential tool for quality control in rubber, plastic, and papermaking industries—promoting the degradation of vulcanized rubber and measuring the tensile force, elongation rate, quantification, and moisture content changes of paper after aging under different temperature and time conditions. the gas aging test of plasticized products, to check its adaptability to storage and operation under high-temperature environment conditions, compare the properties after aging in the air under simulated high temperature and atmospheric pressure.Equipped with an over-temperature protection function that automatically shuts down when overheating, this air circulation aging chamber ensures safe, reliable operation for material durability and performance testing.
Standards
ASTM-D2436. ASTM-D573 ，ASTM F1980 ；
ISO 11607，ISO/DIS 4577;
JIS-K7212.JIS-K6723. JIS-A5756.JIS-C3004. JIS-C3005.JIS-K6301;
UL1581. UL-746B,?UL-1571.62.444;
IEC-540. IEC_60811-1-2.
BS-6746.?BS-903 ;
CNS 3556. CNS 742 ;
parameters:
| Model | Q8795 |
| Test area size W*H*D (cm) | 45*50*45 |
| Exterior chamber size W*H*D (cm) | 105*150*60 |
| Temperature range | RT+25℃~200℃（300℃） |
| Temperature fluctuation | ±0.3℃ |
| Temperature uniformity | ±1%℃ |
| Temp.resolution | 0.1℃ |
| Heating-up time | 30 min 40 min |
| Exterior chamber material | Cold rolled steel plate + Paint |
| Interior chamber material | SUS#304 stainless steel plate |
| Insulation material | PU + fiberglass wool |
| Wind circulation | Centrifugal fan air circulation system |
| Heating system | SUS# Stainless steel high-speed heater |
| Controlling system | Button digital display controller |
| Air exchange rate | 5~200 (3~250)/h |
| Other components | Control status indicator, turntable/compartment shelf (2 freely adjustable) |
| Safety protection device | Phase sequence protection, over temperature protection, overload protection |
| Power supply | AC 3ψ380V 60/50Hz |
| Customization service | Non-standard or special requirements are all welcome |
Features:
1. Easy to operation and the box using CNC machining, elegant design, innovative and adopt counterproductive handle.
2. Internal material is high imported SUS304 mirror Stainless steel or 304B TIG, outside is A3 Steel spray, it improves the texture and appearance of cleanliness.
4. You can visually observe through huge Tempered glass windows with lights anytime and clearly.
5. Good uniformity of temperature
7. With D.50mm test holes on the left side for external test power line or signal line.
Saftey device:
1. With no-fuse protection switch
2. Control system with phase sequence protection and low voltage electrical protection.
3. With over-heat protection switch.
4. Over load protection device for refrigeration compressor.
5. Refrigeration compressor high and low voltage protection switch.
6. Refrigeration compressor over oil pressure protection.
7. Lack of Anti-phase protection system.
8. Overload protection for circulation fan motor.
