Electric Spring Fatigue Furniture Testing Machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The King Size Foam Fatigue Tester is a single-station pneumatic fatigue testing system designed for evaluating the long-term durability, compression resistance, and structural stability of full-size foam mattresses. The tester accommodates standard King and California King mattress sizes and applies controlled cyclic loading to simulate repetitive human use over an extended service life. The system supports both constant force and constant displacement loading modes and is suitable for laboratory-based durability evaluation and standard compliance testing.
Standards
The King Size Foam Fatigue Tester complies with or references the following standards:
ASTM D3574 – Dynamic Fatigue Test by Constant Force Pounding
ISO 2439 – Determination of indentation hardness and deflection
GB/T 26706 – General Technical Requirements for Mattresses (related clauses reference)
Parameters
| Parameter | Unit | Specification |
|---|---|---|
| Test Station | — | Single station |
| Applicable Mattress Size | — | King size, California King |
| Loading Method | — | Pneumatic |
| Loading Mode | — | Constant force / constant displacement |
| Maximum Test Frequency | cycles/min | ≤ 70 |
| Cylinder Stroke | in | 12 (customizable) |
| Indenter Diameter | mm | 250 |
| Load Measurement | — | Fatigue-rated load cell |
| Load Cell Capacity | lb | 500 |
| Positioning System | — | Manual X–Y gantry |
| Sample Retention | — | Four adjustable corner retainers |
| Control System | — | PLC with touchscreen interface |
| Air Supply Requirement | PSI | 80 |
| Power Supply | — | 120 VAC |
Accessories
Circular indenter, 250 mm diameter (ASTM D3574 compliant)
Pneumatic loading cylinder and air regulation components
Fatigue-rated load cell
Manual X–Y positioning gantry
Adjustable mattress corner retainers
PLC controller with touchscreen display
Compressed air connection components
