Horizontal fire resistance test furnace for building materials supplier
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
Building Fire Resistance Testing
Fire resistance evaluation of horizontal structural elements such as floors, slabs, roofs, and horizontal partitions.
Structural Engineering and Construction Materials
Testing of concrete slabs, steel floor systems, composite structures, and protected steel assemblies under standard fire exposure.
Fire Protection Materials
Performance testing of fireproof coatings and fire-resistant treatments applied to horizontal load-bearing components.
Fire Safety Research and Certification
Fire endurance testing to support compliance verification, safety assessment, and technical research.
Standards
The furnace complies with the following standards:
(1) GB/T 9978.1-2008 – Fire Resistance Tests — Elements of Building Construction — Part 1: General Requirements
(2) ISO 834-1 – Fire Resistance Tests — Elements of Building Construction — Part 1: General Requirements
(3) GB/T 9978.3-2008 – Fire Resistance Tests — Elements of Building Construction — Part 3: Commentary on Test Methods and Test Data Application
(4) GB/T 9978.5-2008 – Fire Resistance Tests — Elements of Building Construction — Part 5: Specific Requirements for Loadbearing Horizontal Separating Elements
(5) GB/T 14907-2018 – Test Standard for Fire Protective Coatings for Steel Structures
Parameters
| Item | Specification |
|---|---|
| Number of Burners | 12 proportional flat-flame burners (6 on each side, 5 m furnace length) |
| Operating Temperature | Maximum test temperature 1250 °C |
| Design Temperature | 1350 °C |
| Combustion Mode | Low-speed proportional flat-flame diffusion combustion |
| Gas & Air Pressure | ≤ 4000 Pa |
| Flame Length | ≤ 500 mm |
| Furnace Temperature Measurement Points | 9 points |
| Thermocouple Sleeve Extension | ≥ 25 mm |
| Temperature Accuracy | < ±15 °C |
| Furnace Pressure Measurement | T-type probes, accuracy ±2 Pa, 3 points |
| Data Acquisition Rate | 3 times per second |
| Fuel Gas | Liquefied petroleum gas |
| Equipment Dimensions | 8 m (W) × 8 m (L) × 2.5 m (H) |
| Power Supply | AC 380 V, 70 kW |
| Equipment Weight | Approx. 5 t |
Accessories
(1) Proportional flat-flame burners
(2) Gas solenoid valves and proportional valves
(3) Combustion air blower with frequency inverter
(4) Gas pressure regulators and filters
(5) T-type furnace pressure probes
(6) High-temperature exhaust fan with inverter
(7) Programmable logic controller (PLC) system
(8) Computer-based control and data acquisition system
