Geosynthetic Transmissivity Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The geotextile permeability tester is a testing device designed and developed using the JIGAOTEST system, used to measure the water permeability of geosynthetic materials and related composite materials in the vertical direction.
Application
It is used to measure the characteristics of the plastic drainage plate in the plane direction of the water flow under the specified pressure. During the test, seepage was carried out under the condition that the lateral pressure of the sample was 350kPa and the hydraulic gradient i=0.5. and the water seepage of the sample in a certain period of time was measured.
Standard
JTG E50 T1143-2006:Test Methods of Geosynthetics for Highway Engineering
SL/T:Testing Specification of Geosynthetics for Water Conservancy Projects
JT/T 521- Appendix A-2004:Geosynthetics in Highway Engineering - Plastic Drain Board (Strip)
JTS-206-1- Appendix B B.3-2009:Technical Specification for Application of Geosynthetics in Port and Waterway Engineering
JTS/T245-2023:Testing Specification of Geosynthetics for Port and Waterway Engineering
Parameters
| Description | Details |
|---|---|
| Test chamber structure | Open |
| Effective length of the sample | 400mm |
| Sample width | 100mm (can be customized) |
| Side pressure | 350 + 20kPa (gauge accuracy 0.4%FS) |
| Head difference adjustment range | 0 - 400mm |
| Accuracy | 0.4% |
| Dimensions - Host | 715x300x260mm |
| Dimensions - Water tower | 440x440x860mm |
| Weight | 35kg |
