Plastic Pipe Hydrostatic Pressure Burst Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Plastic Pipe Hydrostatic Pressure Burst Tester is suitable for hydrostatic pressure burst testing of PVC, PE, aluminum-plastic composite pipes, and other similar materials. Based on the fundamental principles of material mechanics and fluid mechanics, it simulates the pressure conditions that pipes may experience in real-world applications by applying gradually increasing pressure to the inside of the pipe, thereby evaluating the pressure resistance and safety performance of the pipe. It features both computer and manual control, and is equipped with a constant temperature water tank for automatic temperature control. This testing machine fully complies with relevant national standards and can be customized according to specific requirements. During the test, pressure changes, test time, and other data can be monitored in real-time through the data display interface on the LCD screen. Simultaneously, the deformation of the pipe and any other abnormal conditions should be closely observed.
Standards
ISO 1167: For thermoplastics pipe systems under constant internal pressure
ASTM D 1598: Standard test method for time-to-failure of plastic pipe under constant internal pressure
ASTM D 1599: Standard test method for resistance to short-time hydraulic pressure of plastic pipe
ASTM F1335:Standard Specification for Pressure-Rated Composite Pipe and Fittings for Elevated Temperature Service
ISO9080:Plastics piping and ducting systems - Determination of the long-term hydrostatic strength of thermoplastics materials in pipe form by extrapolation
Technical Parameters
| Parameter | Specification |
|---|---|
| Pressure Range | 0–50 MPa (customizable up to 100 MPa) |
| Testing Stations | 45 (expandable to 60) |
| Pump Type | Variable Frequency Drive (VFD) |
| Power Supply | 220V/50Hz or 110V/60Hz (CE/UL certified) |
| Control System | PLC + HMI Touchscreen |
| Data Interface | Ethernet (TCP/IP), USB 2.0. Wi-Fi |
| Operating Environment | 5–40°C, ≤85% RH (non-condensing) |
| Dimensions (L×W×H) | 950mm × 850mm × 1800mm |
| Weight | 450 kg (net) |
