Gas Jet Erosion Rig/Jet Erosion Test Rig
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Gas Jet Erosion Rig is a laboratory testing system designed to evaluate erosion wear behavior of materials and coatings subjected to high-velocity particle-laden gas flow. You use this equipment to simulate solid particle impact erosion under controlled conditions by adjusting particle velocity, mass flow rate, impingement angle, and specimen orientation. It is suitable for standardized testing and comparative analysis of metals, ceramics, polymers, and coated surfaces.
Application
You can apply the Gas Jet Erosion Rig in the following scenarios and material evaluations:
(1) Erosion resistance testing of metallic materials, ceramics, polymers, and composite materials.
(2) Performance evaluation of hard and soft coatings, including wear-resistant and protective coatings.
(3) Aerospace component erosion testing, such as turbine blades and structural parts.
(4) Wind energy component evaluation, including erosion of wind turbine blades.
(5) Industrial equipment and pipeline erosion assessment under particle-laden gas flow.
(6) Automotive coating durability and surface protection studies.
(7) Academic research and teaching in material erosion and wear mechanisms.
(8) Quality control, process optimization, and service life assessment of coated components.
Standards
You can conduct erosion tests in accordance with the following international standards:
(1) ASTM G76 – Standard Test Method for Conducting Erosion Tests by Solid Particle Impingement Using Gas Jets
(2) DIN 50332 – Erosion Testing by Particle Jet Method
(3) ISO 20567-1 – Paints and Varnishes – Determination of Stone-Chip Resistance – Part 1
(4) ISO 20567-2 – Paints and Varnishes – Determination of Stone-Chip Resistance – Part 2
Parameters
| Parameter | Specification |
|---|---|
| Particle Nozzle | Inner diameter 4.7 mm, length 300 mm, stainless steel |
| Nozzle Height Adjustment | Adjustable nozzle-to-specimen distance |
| Specimen Holder | Tiltable, specimen size 50 × 50 mm |
| Particle Velocity (Standard Mode) | 25 – 80 m/s at 1.5 bar |
| Particle Velocity (Enhanced Mode) | Up to 120 m/s at 4 bar |
| Particle Mass Flow Rate | 0.2 – 2 g/min |
| Gas Heating | Optional, up to 100°C |
| Power Supply | 220/240 V, single phase, 50 Hz, 1.5 kW |
| Compressed Air (Standard Mode) | 1.5 bar, 3.5 cfm |
| Compressed Air (Enhanced Mode) | 4 bar |
| Installation Dimensions | 1000 × 1200 × 400 mm |
| Installation Type | Floor-standing |
