Electric pencil hardness tester

Whats/App: +86 156 1874 6768

Web: standard-groups.com

The Electric Pencil Hardness Tester is designed to determine the surface hardness of coating layers applied to finished products by means of a standardized pencil scratch method. The instrument provides stable loading, constant angle, and uniform motion, ensuring accurate and repeatable hardness evaluation of painted, sprayed, or coated surfaces. It is widely used for quality control, product inspection, and coating performance assessment in electronics and appliance industries.

Application

(1) Surface hardness testing of spray coatings on consumer electronics housings (mobile shells, laptop computer shells)

(2) Hardness evaluation of coated plastic and metal parts used in home appliances (TV frames, air conditioner panels, washing machine panels)

(3) Quality control testing of decorative and protective coatings in manufacturing processes

(4) Comparative testing of different coating formulations and curing conditions

(5) Inspection of finished products for coating consistency and scratch resistance

Standards

(1) GB/T 6739-2022 — Paints and varnishes — Determination of film hardness by pencil test

(2) ISO 15184 — Paints and varnishes — Determination of film hardness by pencil test

(3) ASTM D3363 — Standard Test Method for Film Hardness by Pencil Test

Features

(1) Electric drive system ensures stable and uniform test platform movement

(2) Fixed 45° test angle in accordance with international pencil hardness standards

(3) Adjustable test loads to meet different standard requirements

(4) Simple structure and easy operation suitable for routine laboratory testing

(5) Good repeatability and reduced operator influence compared with manual testing

Parameters

ItemDescription
Test angle 45°
Test load 500 g / 750 g / 1000 g, adjustable
Platform moving speed Adjustable
Travel distance 40 mm
Test platform size Approx. 120 × 170 mm
Sample fixation Fixed platform
Power supply AC 220 V, 50 Hz
