Flame Retardant Testing Machine
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
It primarily evaluates the burning performance of fabrics by observing the rate at which flames spread across them, conforming to relevant standards such as FZ/T 01028-1993. The tester features high precision and stability, ensuring the accuracy and reliability of the test results.
Application
It can accurately test the flame spread speed. Equipped with different sample clamps and accessory test kits to meet various testing standards, the automatic gas control system allows for easy control of the testing process. It is suitable for determining the flame retardant properties of flame-retardant woven fabrics, knitted fabrics, coated products, laminated products, etc. It is used to determine the tendency of textiles to continue burning, smolder, and char.
Standard
ISO 3795:Road vehicles, and tractors and machinery for agriculture and forestry - Determination of burning behaviour of interior materials
FMVSS 302:Federal Motor Vehicle Safety Standard No. 302 - Flammability of interior materials
DIN 75200:Determination of burning behaviour of interior materials in motor vehicles
SAE J369:Test Method for Flammability of Polymeric Interior Materials - Horizontal Test
ASTM D5132:Standard Test Method for Horizontal Burning Rate of Polymeric Materials Used in Occupant Compartments of Motor Vehicles
JIS D 1201:Automotive interior materials - Determination of burning behaviour
AU 169:Flammability of materials used in the interior construction of motor vehicles
GB 8410:Flammability of automotive interior materials
Feature
Flame Retardant Tester is designed for testing plastic runway surface layers, featuring precise dimensions (650mm x 500mm x 840mm) and a reliable ignition system with a 25mm diameter thincotton disc. It operates on AC22ov 30w power supply and uses 96% industrial alcohol as the combustion medium. Backed by a 1-year warranty and customizable via OEM, ODM, or OBM support, this tester ensures quality through rigorous pre-production and final shipment inspections.
Parameters
| Feature/Specification | Details |
|---|---|
| Dimensions | Length: 650mm, Depth: 500mm, Height: 840mm |
| Fume Hood and Exhaust Pipe | Includes a fume hood with an 80mm diameter smoke exhaust pipe connection |
| Material of Fume Hood and Internals | Brushed stainless steel |
| Ignition Material | Thin cotton disc with a diameter of 425mm |
| Combustion Medium | 96% industrial alcohol |
| Power Supply | AC220V, 30W |
| Style Requirements | Styles should be cut from different positions of the test object; style specification: 100mm x 100mm; generally, 5 styles should be measured per test |
| Pre-test Pattern Conditioning | The pre-test pattern should be placed in the test environment for more than 48 hours |
