Air filter System（ISO 16890/EN 779）
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
Filter test system for general air filters according to ISO 16890, EN 779, ASHRAE 52.2
The Filter Test System has been developed especially for air filter testing according to standards ISO 16890, EN 779 and ASHRAE 52.2. We can fall back to a long-standing expertise in the field of construction and installing of filter test systems.
In the filter test stand the filter samples can be easily installed into the rotatable and movable duct sections. A filtrated air flow is loaded with particles. In this way information about the efficiency of the filters will be obtained. With these results the filter samples can be rated and classified.
Applications
Testing of general air filters according to ISO 16890
Standard
ISO 16890，EN 779，ASHRAE 52.2
Features
Measurements according to standards ISO 16890, EN 779:2012 and ASHRAE 52.2-2008
high grade of automation, mostly automated test runs with complete operator guiding through all tests, data handling and protocols
energy efficiency rating for filters according to EUROVENT
MERV-filter classification (Minimum Efficiency Reporting Value) for coarse dust filters and fine particle filters
rotatable duct sections
universal filter holding system
safety functions realized in a PLC
Technical data
| Parameter | Unit | Value |
|---|---|---|
| Test flow rate | m³/h | 600 … 6000 |
| Measuring range, differential pressure | Pa | max. 2000 |
| Compressed air supply (operating gas/air) | bar | max. 6 |
| Power supply | – | 3 × 400 VAC, 125 A, 50 Hz |
| Operating medium (aerosol substances) | – | DEHS, KCl, ISO 12103-1 A2 / A4 |
