Air Flow Velocity Distribution Test System
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
Test System for the characterisation of the air flow velocity profile of components (e.g. tubes, filters).The air flow velocities between 1-40 m/s and turbulences in the outlet of flowed through units under test can be measured.
Through this, a good position for flow velocity measuring devices (for example MAFs) in flowed through parts (for example motor inlet filters) can be found easier, taking into consideration a range of air flow rates. The data created by the flow scanner can also be used to check models for flow simulation.
Applications
development of filter housings and air-ducting elements in general
comparison of models for flow simulation with measured values
Flow field uniformity analysis of air filters and filter assemblies;
Flow behavior evaluation of engine intake systems and intake filter housings;
Optimization of installation positions for air velocity and mass air flow sensors (e.g. MAF sensors);
R&D validation of ventilation equipment, air supply modules, and air handling units;
Comparison and verification of CFD simulation results with measured data;
Performance assessment of new air duct designs, guide vanes, and flow straightening structures.
Standards
The system can be used in accordance with the following standards and technical references:
(1) GB/T 1236 Industrial Fans – Performance Testing Methods
(2) GB/T 10178 Industrial Fans – Field Performance Testing
(3) ASHRAE Handbook – Fundamentals (Air Flow Measurement and Testing Sections)
Technical data
| Parameter | Unit | Value |
|---|---|---|
| Test flow rate | m³/h | 20 … 900 |
| Air flow velocity | m/s | 1 … 40 |
| Test specimen dimensions | mm | max. 485 × 600 |
| Differential pressure of test specimen | Pa | – |
| System dimensions (W × H × D) | mm | 2500 × 2660 × 1300 |
| Weight | kg | approx. 550 |
