Automotive HVAC Manikin
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Automotive HVAC Manikin is designed to evaluate thermal comfort and air distribution inside automobile, truck, and indoor HVAC environments.It simulates the thermal response of a seated human occupant, providing accurate data on airflow, temperature, radiant heat, and humidity distribution.
Application
This system is widely used for:
Vehicle heating, ventilation, and air conditioning (HVAC) system design and validation
Passenger comfort optimization in automotive and public transport cabins
Indoor building HVAC testing, including air circulation and comfort assessment
R&D and academic studies on human thermal comfort and airflow dynamics
Standards
The Automotive HVAC Manikin complies with the following international standards:
ISO 14505-2: Ergonomics of the thermal environment — Evaluation of thermal environments in vehicles
ISO 7726: Instruments for measuring physical quantities of the thermal environment
ASHRAE Standard 55: Thermal Environmental Conditions for Human Occupancy
SAE J2234: Vehicle climate control system performance testing
EN ISO 15831: Clothing — Physiological effects — Measurement of thermal insulation by a thermal manikin
Specifications
| Item | Specification / Description |
|---|---|
| Body Type | Male and small male articulated thermal manikin |
| Height | 178.5 cm (standard male) / 168.4 cm (small male) |
| Chest | 90.8 cm (35.7 in) |
| Waist | 73.2 cm (28.8 in) |
| Hip | 91.8 cm (36.1 in) |
| Weight | 23 kg (50 lbs) |
| Surface Area | 1.8 m² (19 ft²) |
| Air Temperature (46 sensors) | Range: -20°C to +70°C; Accuracy: ±1.0°C; Resolution: 0.1°C |
| Air Velocity (46 sensors) | 0.1–5.0 m/s, omnidirectional; temperature-compensated (-20°C to +70°C) |
| Dual Spectrum Radiant Heat Flux (46 sensors) | Up to 2,000 W/m²; Wavelength range: 1–20 μm |
| Relative Humidity (4 sensors) | 0–95% RH, non-condensing |
| Operating Range | Temperature: -20°C to +50°C; Humidity: 0–95% RH |
| Power Supply | 12V DC vehicle power outlet or external AC adapter |
| Data Communication | Ethernet and 802.11g wireless |
| Software | ThermDAC system with real-time monitoring and analysis |
| Construction Material | Carbon fiber / epoxy composite body |
| Manikin Geometry Data | Available in CAD format for CFD simulation |
