Continuous Load Surface Performance Measurement Instrument
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Continuous Load Surface Performance Measurement Instrument is designed for evaluating coating adhesion, friction resistance, scratch resistance, and peeling behavior under continuously increasing load conditions. By applying proportional vertical loading during controlled linear motion, the instrument enables precise detection of surface performance changes and critical failure points, making it suitable for detailed analysis of coating durability and interfacial properties.
Application
Adhesion strength evaluation of surface coatings
Measurement of friction resistance between coatings and contact tools
Scratch resistance testing of thin and thick film coatings
Peeling resistance assessment under continuously increasing load
Surface performance characterization of films, coatings, and laminated structures
Typical test samples include:
Thin and thick coating layers
Painted and varnished surfaces
Polymer films and sheets
Decorative panels and laminated materials
Coated metal or non-metal substrates
Standards
GB/T 6040-2008 Test Method for Wear Resistance of Metal Surfaces
GB/T 17657-2022 Test Methods of Evaluating the Properties of Wood-Based Panels and Surface-Finished Panels (including abrasion and scratch tests)
ISO 20502 Fine Ceramics and Coatings — Scratch and Wear Testing
ISO 1518 Paints and Varnishes — Determination of Resistance to Scratching
ASTM D3702 Test Method for Wear Rate of Materials Using a Rotating Drum Apparatus
ASTM D1894 Test Method for Static and Kinetic Coefficients of Friction of Plastic Film and Sheeting
JIS P 8139 Determination of Friction and Wear Properties of Coatings
JIS P 8147 Determination of Surface Friction Coefficient and Scratch Properties of Coatings
JIS K 7317:2022 Plastics — Film and Sheeting — Determination of Coefficient of Friction
Parameters
| Parameter | Specification |
|---|---|
| Sliding speed | 60 – 600 mm/min |
| Sliding distance | 1 – 50 mm |
| Motion mode | SINGLE mode: stops automatically after preset distance |
| REPEAT mode: reciprocating motion, up to 9.999 cycles | |
| Load range | 0 – 100 gf / 0 – 1000 gf |
| Vertical load | 0 – 50 g / 0 – 500 g |
| Maximum sample size | 220 × 100 mm, thickness up to 8 mm |
