Surface Performance Tester STD-FB4-A
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Surface Performance Tester is a high-precision instrument designed to quantify the surface friction and roughness characteristics of fabrics, paper, nonwoven materials, and films. By simulating the tactile “stroking” motion of artisans and professionals, this device accurately measures friction coefficients, surface roughness, and displacement variations. The results provide objective data for tactile attributes such as fullness, smoothness, and stiffness, making it widely applicable in textile, paper, and film industries for research, quality control, and material evaluation.
Application
The Surface Performance Tester is suitable for a broad range of surface property evaluations, including:
Textile Industry: Surface performance testing of fabrics, fibers, and nonwovens.
Paper Industry: Measurement of surface friction and roughness of various paper types.
Film Materials: Evaluation of friction and roughness of films and membrane-like samples.
Coatings: Assessment of surface friction properties of coated materials.
Polymeric Materials: Surface evaluation of engineering plastics and polymer sheets.
Surface Treatment: Comparison of friction and roughness before and after surface treatments.
Research Institutions and Universities: Study of material tribological properties and surface structures.
Quality Control: Inspection of raw materials and finished products to ensure consistency of surface properties.
Standards
The Surface Performance Tester complies with the following standards:
(1) GB/T 1804 – Test methods for surface friction of textiles
(2) GB/T 12915 – Friction testing of nonwoven fabrics
(3) GB/T 19392 – Friction coefficient testing of paper
(4) ISO 8295 – Determination of frictional properties of textiles
(5) ISO 25178 – Surface roughness measurement
(6) ASTM D1894 – Coefficient of friction of plastics
(7) JIS L 1096 – Friction properties of textiles
(8) ASTM D3354 – Surface friction properties of textiles
Parameters
| Parameter | Specification |
|---|---|
| Testing Methods | Friction measurement, surface roughness measurement, surface displacement measurement |
| Maximum Friction Force | 200 gf |
| Friction Force Accuracy | ±0.5% full scale |
| Surface Roughness Accuracy | ±1.0% full scale |
| Maximum Surface Displacement | 30 mm |
| Surface Displacement Accuracy | ±0.5% full scale |
| Surface Roughness Sensor | Differential transformer |
| Surface Displacement Sensor | Potentiometer |
| Measurement Speed | 1 mm/sec |
| Sensor Dimensions | Friction probe: 10 × 10 mm; Roughness probe: 5 mm width |
| Operating Environment | 20–30°C, 50–70% RH |
| Power Supply | AC 100 V, max 50 W (air compressor 100 W) |
| Dimensions (W × D × H) | 550 × 520 × 420 mm |
| Weight | 50 kg |
