Film impact tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
A Film Impact Tester is a device designed to measure how well a film or thin material can withstand sudden impact or shock without breaking, cracking, or puncturing. It is commonly used in laboratories and quality control environments.
Product Introduction
The film impact testing machine, through the hemispherical punch at a certain speed, impacts and passes through the film sample, measures the energy consumed by the punch, and evaluates the anti-pendulum impact energy of the film sample.
The sample to be measured is placed in the middle of two splints to clamp, and the pendulum is adjusted by counterweight to form enough mechanical energy to impact the surface of the sample to be measured during the impact process to break down or not break down the sample to be measured. The energy borne by the sample to be measured is the loss part of the total mechanical energy formed by the pendulum during the impact process, and is read out on the dial through the pointer.
standards
(1)ASTMD3420-2014
(2)GB8809-2015
(3)GB/T 20624.1—2006/ISO 6272-1:2002
(4)ASTM D2794—2019
Applications
(1)Packaging Materials
Test the impact resistance of plastic films, laminates, and flexible packaging materials.
Evaluate durability for bags, pouches, wraps, and protective films.
(2)Plastic & Polymer Films
Assess brittleness, toughness, and impact strength of PVC, PE, PET, and other polymer films.
Ensure materials meet quality and safety standards.
(3)Industrial Films & Coatings
Evaluate surface coatings, laminates, and protective films for mechanical stress tolerance.
Determine suitability for automotive, electronics, or construction applications.
(4)Research & Development
Used in laboratories and universities for materials testing, formulation optimization, and durability studies.
Supports R&D of new polymer blends, laminates, and film products.
(5)Quality Control & Production Monitoring
Ensures film materials meet industry or customer specifications before shipment.
Helps identify manufacturing defects and improve production consistency.
(6)Standards Compliance
Supports testing according to ASTM, ISO, and other international standards for film impact resistance.
Performance parameters
- Full range of dial: 3J/(30cm.kgf)
- Maximum impact energy: 3J
- Hammer diameter: Φ25.4mm: suitable for test specimens with diameter of medium 50-60 (Class A test in the standard); Φ19mm: Suitable for testing specimens with a diameter of 89 (Class B test in the standard)
- Reading dial minimum scale value: 0.020J/ grid (0.20cm.kgf)
- Specimen clamp diameter: Φ89mm, Φ60mm
- Swing range: R300mm
- Swing Angle: 90°
