Gas Oxidizing Properties Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Gas Oxidizing Properties Tester is a device used to assess the oxidizing characteristics of gases. It evaluates a gas’s ability to act as an oxidizer, potentially supporting combustion or causing chemical reactions, under controlled laboratory conditions.
Product Description
This tester is used to determine whether the oxidizing property of a gas or gas mixture is higher than that of air. It can be used for testing toxic, corrosive gases or their mixtures.
Scope of Application and Standards
The tester is used to determine whether a gas or gas mixture has an oxidizing property higher than air, applicable to toxic and corrosive gases or their mixtures.
Complies with the following standards:
ISO 10156-2010. Part 4: Selection of Cylinder Valve Outlet by Determination of Combustion Potential and Oxidizing Ability of Gases and Gas Mixtures
GB/T 27862-2011. Part 4: Test Methods for Classification of Chemical Hazards — Combustion Potential and Oxidizing Ability of Gases and Gas Mixtures
Technical Specifications
| Parameter | Specification |
|---|---|
| Working Environment | 5℃–40℃, <85% RH |
| Test Chamber Material | Stainless Steel 316L |
| Test Chamber Pressure Resistance | ≥5000 kPa |
| Test Chamber Volume | ≥0.005 m³ |
| Accessories | Magnetic stirrer with adjustable speed |
| Ignition System Metal Rod Diameter | ≥3 mm |
| Nichrome Wire Diameter | 0.05–0.2 mm |
| Ignition Energy | 10–20 J |
| Explosion Pressure Sensor Range | 0–4000 kPa |
| Explosion Sensor Pressure Resistance | ≥6000 kPa |
| Explosion Sensor Accuracy | ±0.1% FS |
| Explosion Sensor Response Time | ≤1 ms |
| Gas Distribution Sensor Range | 0–200 kPa |
| Gas Distribution Sensor Accuracy | ±0.1% FS |
| Temperature Measurement Range | 0–150℃ |
| Temperature Measurement Accuracy | ±1℃ |
| Main Unit Dimensions | 830 mm × 650 mm × 1200 mm |
| Electrical Control Box Dimensions | 320 mm × 500 mm × 500 mm |
| Weight | 280 kg |
| Main Unit Power Supply | AC 220V ±10%, 50 Hz ±3 Hz |
| Rated Power | 400 W |
| Ignition Power | 3000 W |
Functional Features
Separate design for the testing apparatus and control system, ensuring safety of both the operator and instrument.
Comes with PC operation software to reduce operational difficulty.
Supports remote ignition for operator safety.
Equipped with high-precision pressure sensors to accurately measure explosion pressure and control gas partial pressure and mixture concentration.
Magnetic stirrer for uniform gas mixing.
Electronic microprocessor control of ignition timing.
Automatic cleaning function.
Automatic pressure relief option after testing, releasing pressure in the test chamber.
Multiple explosion-proof features to protect personnel.
Automatic fault detection and audiovisual alarm system.
Fully automated test process, supporting parameter setting, data storage, and report generation without manual intervention.
