Common Types Of Check Valves
Common Types Of Check Valves
A is a valve whose switching parts are disc-shaped and rely on their own weight and medium pressure to produce the effect of stopping the medium from flowing back. It is an automatic valve, also known as a one-way valve, check valve, backflow valve, or isolation valve. The commonly used check valves are as follows.
Swing check valve
Swing check valves have a disc-shaped valve flap and rotate around the axis of the valve seat channel. Because the internal passage of the valve is streamlined, the flow resistance is higher than that of a lift check valve. Small size, suitable for medium, small diameter, low pressure, and large diameter pipeline (large diameter case flow rate is low and infrequent flow changes). Sealing performance is not as good as lifting type.
- The installation position of the swing check valve is not restricted, it can be installed on horizontal, vertical, or inclined pipelines.
