Metal Wire Bending Fatigue Tester
Main uses:
Metal wire repeated bending tester used for repeated bending test of wire, for different specifications of wire bending radius can be replaced with different round rod, bending position （height） can be adjusted, perforation diameter to replace different bushings.
Test principle:
The sample of a certain diameter is clamped in two round rods of specified size, press the button, the sample is bent at about 90°, the sample is broken, and the bending number is automatically stopped, and the bending number is recorded to test the performance of the metal wire under plastic deformation and the defects displayed during repeated bending.
Meet the standard:
GB/T 238-2013 "Metal material wire repeated bending test method"
GB/T 235 "Metal material thickness is less than or equal to 3mm sheet and thin strip repeated test method"
ISO/DIS 7801-1983 "Repeated bending test of metal wire"
Main parameters:
1, sample diameter: 0.3——6mm or 4——10mm
2, sample length: 150——200mm
3, bending Angle: left and right bending 90 degrees
4. Bending speed: 60 times/min
5. Counting range: 0-9999 times
6. Motor power: 1.1KW
