Hydraulic Pump Contamination Resistance Tester
Hydraulic pump pollution resistance test bench is mainly used to detect the fuel pump in the specified concentration of pollution in the operating medium when the fuel pump to withstand the characteristics of pollution.
Test Object:
Fuel Pump
Test Item:
Fuel Pump Pollution Resistance Test
Technical Parameters:
1. Test oil: RP-3 aviation kerosene
2. Test powder: in accordance with the provisions of Table II of GJB.1003.1996.
3. Medium temperature: 10-40 ° C
4. Purification cleanliness: -/12/10 (GB/T
5. Test flow: 150 ~ 750L / min (fuel pump J / RLB-160; fuel pump J / RLB155-011); 250 ~ 1150L / min (fuel pump J / RLB-162).
6. Test pressure: 0 ~ 1MPa
7. Fuel tank volume: 1000L
8. Equipment power supply: AC 380V / 50Hz
9. Equipment power: 25kW
10. External dimensions: 5000 × 200 × 2000 (L × W × H) (subject to measurement)
11. Weight: 1000kg
Range of variation of instrument accuracy and test conditions:
1. Pressure kPa: 0.5% FS
2. Flow rate L/min: 0.5%FS
3.Temperature ℃: Class A
Main structure description:
(1) Stirring oil tank, working oil tank with conical oil tank, stirring oil tank installed inside the agitator
(2) Circulation pump circulates stirring and cooling; oil is discharged from the working oil tank.
(3) Bypass circulation purification
(4) pump casing fixed in the working tank box, the working tank box below the installation of the oil plate
(5) two sets of flow measurement devices through the manual switching valve conversion
