Floor Caster Wear Tester
A floor caster wear tester is a specialized machine designed to evaluate how well casters (the wheels on chairs, furniture, carts, etc.) stand up to repeated use and abrasion on different types of flooring materials.
How it works:
The chair casters that can be moved and adjusted are controlled by the floor covering castor wear resistance tester. The resilient floor and laminated floor covering are placed on the test bench.
The castor is started by the castor floor testing machine and acted on the resilient floor and laminated floor covering placed on the test bench. Stop automatically after the specified test time or number and take off the sample to see its change!
Meet the standard:
GB/T 11982.2, GB/T 4085, BS/EN 425, ISO 4918-2009
Technical parameters:
Host size: Length 1500mm* Width 1700mm*1620mm
Floor replacement base: 1350mm*1350mm（square, adjustable within this range）
Rotary diameter: 950mm
Total load load weight: 0-1500 lb （Note: 1 lb =0.4536 kg）
Rotary lifting distance: 400mm
Rotation speed adjustment range: 0-60 RPM, platform speed: （19±1）r/min, rotation （180±10）S after the platform stops and remains stationary （5±2）S, and then reverse operation.
Turntable counting range: <1 million times
Turntable tooling card number: 3
Wheel: Caster wheel diameter: ￠50±2mm, width 23±3mm, crank distance: 32±2mm
Wheel hardness: Shore A（95±5）mm
Distance from caster to platform: （198±1）mm
The distance between the three casters is: （130±1）mm, the spacing is 120°, and the installation distance between any two casters is: （225±5）mm
