Car seat belt locking performance tester
The Car Seat Belt Locking Performance Tester is a professional testing system designed to evaluate the emergency locking function, acceleration response, displacement behavior, and locking distance of automotive seat belt retractors. Built for high reliability and precision, it supports comprehensive safety performance testing required by automotive manufacturers, component suppliers, certification bodies, and research institutions. The system offers automated control, multi-angle configuration, high-accuracy sensors, and fast data acquisition to ensure consistent and repeatable testing results.
Product Features
1、Advanced PLC Control System
Ensures stable test execution, automated operation, and precise data processing.
2、User-Friendly Interface
Equipped with a color touchscreen interface supporting Chinese/English switching, improving usability for global operators.
3、Multi-Angle Mounting Design
Supports retractor mounting at 45°, 90°, 135°, and 180° to simulate various vehicle installation conditions.
4、High-Precision Acceleration Simulation
Acceleration range of 0.2–1.5 g with fine adjustment steps ≤ 0.05 g for accurate test condition configuration.
5、High-Accuracy Sensor System
Acceleration accuracy < 0.01 g; locking distance accuracy ≤ 0.01 mm ensures trustworthy measurement results.
6、Fast Emergency Locking Simulation
Achieves 2.94 m/s within 50 ms, replicating real-world emergency braking and impact scenarios.
7、Industrial-Grade Mechanical Structure
Stable, durable, and designed for long-term continuous operation in professional laboratories.
Applicable Standards
1、GB 14166-2013
Seat Belts, Restraint Systems, Child Restraint Systems and ISOFIX Child Restraint Systems for Motor Vehicle Occupants
2、GB 27887-2011
Restraint System for Child Occupants of Motor Vehicles
Technical Parameters
| Parameter | Specification |
|---|---|
| Control System | PLC automation + data processing |
| Operation Interface | Color touchscreen (Chinese/English) |
| Emergency Lock Test Speed | 2.94 m/s within 50 ms |
| Mounting Angle Options | 45°, 90°, 135°, 180° |
| Acceleration Adjustment Range | 0.2–1.5 g |
| Acceleration Adjustment Step | ≤ 0.05 g |
| Maximum Sled Displacement | 100 mm |
| Inductive Acceleration Range | ≥ 0.2–2.5 g |
| Acceleration Measurement Accuracy | < 0.01 g |
| Acceleration Repeatability | ≤ ±0.01 g |
| Acceleration Overshoot | < 10% of set value |
| Locking Distance Accuracy | ≤ ±0.01 mm |
