Elastic Tape Fatigue Testing Machine
Product Introduction:
This instrument is used to test the elasticity of elastic belt after reciprocating movement.
Standards:
SATRA TM103
Application:
Elastic Tape Fatigue Testing Machineis used to determine its repeatedly extend performance under maximum extension for elastic fabric and elastic band, also can be used to determine fatigue resistance of extensible material.
Purpose:
The instrument is designed for measuring the extensibility and repeatability of elastic tape, cloth and other elastic materials under the maximum stretch.
Feature:
Principle: Drive the elastomer sample to repeatedly elongate until it reaches effective growth limit. Regularly evaluate the damage and stop test when it reaches test times or damage exceeded a predetermined level.
Product Parameters:
1. Sample set: 1 set
2. Maximum stroke: 150mm
3. Test clip width: 170mm
4.Speed: (65±5) cpm
5. Counter: six-digit LCD display, 0 —— 999.999
6. Volume: (60X30X40) cm
7. Weight: about 50kg
8. Power supply: AC220V 50Hz
