Automatic freezing point pour point cold tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The automatic freezing point pouring point Freezing point tester is suitable for petroleum, biological, chemical and other fields, and is used to accurately determine the freezing point/pouring point/freezing point/turbidity point of jet fuel, biofuels, lubricating oil, coolant and other substances.
Reference standard:
SH/T 0770. ASTM D5972
SH/T 0771. ASTM D5949
GB/T 510
ASTM D5773
Product features:
1) Using advanced automatic phase conversion method and pressure pulse method test, more accurate and efficient
2) The sample size is small, the test cost is low and the pollution is small
3) Built-in Sterling temperature control module, no need for external cooling, high integration
4) The frame-by-frame scanning dynamic comparison algorithm was used to accurately judge the phase transition state of the sample
5) Preset standard test methods, you can freely choose test items
6) Real-time display of temperature and optical signal strength curve, the test process is more intuitive
7) Automatic selection of pulse pressure, automatic heating of sample cup, easy cleaning:
8) Key components are internationally renowned brands to ensure long-term stable operation
9) Hierarchical user management, can achieve different levels of account management control
10)USB interface plug and play, optional thermal printer, easy data management
11)7 inch color touch screen, support Chinese input, intuitive and simple operation
Technical parameters:
|
Operating Environment |
(0～30)℃,＜85%RH |
|
Temperature Range |
(-80～55)℃ |
|
Rising Rate |
(15±5)℃/min, (10±0.5)℃/min, (1.5±0.1)℃/min |
|
Temperature Detection Accuracy |
±0.1℃ |
|
Sample Volume |
0.15mL |
|
Measurement Method |
Freezing point, turbidity point: automatic phase conversion method; |
|
Pour Point Test Interval |
Pouring point, condensation point: automatic pressure pulse method |
|
Repeatability |
1℃ or 3℃ |
|
Reproducibility |
Freezing point: 0.69℃; |
|
Storage Space |
Pouring point: 1.6℃@1℃, 2.2℃@3℃; condensation point: 2.0℃; Turbidity point: 1.3℃ Freezing point: 1.3℃; Pouring point: 3.2℃@1℃, 2.2℃@3℃; condensation point: 4.3℃; Freezing point: 4.0℃; Freezing point: 4.3℃; Pouring point: 2.2℃@3℃; Freezing point: 1.0℃ 3℃; |
|
Interface |
Freezing point: 2.0℃; |
|
Power Supply |
Turbidity point: 1.3℃ |
|
Power |
Freezing point: 1.3℃; |
|
Dimensions |
Pouring point: 3.2℃@1℃, 3.8℃@3℃; |
|
Weight |
Freezing point: 4.0℃; |
