AATCC Viewing Board
Application
- Textile Mills: Assesses surface defects, wrinkles, and seam smoothness post-washing.
- Garment Manufacturers: Inspects finished apparel for oil stains, creases, and blemishes.
- Quality Control Labs: Validates compliance with AATCC and ISO appearance standards.
- Retail & Brand Inspection: Ensures product aesthetics meet consumer expectations.
Standard
- ISO 7768: Durable Fabric Surface Evaluation After Washing
- ISO 7769: Wrinkle Assessment Post-Household Washing
- ISO 7770: Fabric Joint Flatness Evaluation
- AATCC 88B/88C: Seam Smoothness & Pleat Retention After Washing
- AATCC 124: Fabric Surface Appearance Post-Repeated Washing
Product Advantages
Standardized Lighting: Dual 40W cold-white fluorescent lamps ensure consistent color assessment.
Magnetic Sample Fixation: Quick-release magnets secure fabrics without slippage.
Portable Design: Casters enable easy relocation for multi-station use.
Ergonomic Viewing: 5° angled board and 1.5m height reduce operator fatigue.
Global Compliance: Meets AATCC, ISO, and IWS standards for textile inspection.
Durable Construction: White enamel shade and heavy-duty frame withstand daily use.
Product Features
- Dual Lighting System: 2.4m (8ft) cold-white fluorescent tubes with rapid preheating.
- AATCC Gray Scale Visor: Level 2 gray (matt) visor for accurate stain/blemish grading.
- Adjustable Floodlights: 500W panlights with 1.5m ground clearance for directional illumination.
- Magnetic Fixation: Samples are held in place without clamps or adhesives.
- Mobile Base: Casters allow movement across labs or production lines.
- Non-Reflective Surface: White enamel observation board minimizes glare.
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Mode | Manual (Visual Inspection) |
| Light Source | 2 × Cold White Preheating Fluorescent Lamps (40W each) |
| Tube Length | 2.4 m (8 ft) |
| Floodlight Power | 500W (Adjustable) |
| Visor Color | AATCC Level 2 Gray (Matt) |
| Visor Size | 600 mm × 400 mm × 12 mm |
| Observation Board Angle | 5° (Ergonomic Tilt) |
| Board Color | ISO/AATCC Level 2 Gray Scale |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 254 cm × 70 cm × 255 cm |
| Net Weight | 180 kg |
| Casters | 4 × Lockable Wheels (360° Rotation) |
