polyester geogrid 80kn
The polyester geogrid is a kind of reticular structural material with PVC coating.They are manufactured from high tensile and modulus polyester yarn,formed by weaving technics,then the joints comes into being stable bearing force,which can fully display its mechanics performance.
Index properties units Longitudinal Values Transverse Values
•Aperture dimensions mm 25.4 25.4
•Minimum tensile strength kn/m 40 40
•Utmost elongation % 13 13
•Weight per area g/m2 200 --
•PVC surface sizing % 20 20
Brief Introduction
•High intension,high tenacity,erosion-resistance,light weight
•Reinforce soft soil roadbed,rib side slope of embankment,enhance isolation,inhibit ground deformation,prevent crack by reflection,increase strength of roadbed.
•Large friction coefficient with soil or gravel
Application
•Roadbed reinforcement of road and railway,crack prevention,increase of roadbed strength
•Reinforcement and stabilization of riverside,embankment and side slope
•Dyke reinforcement on soft ground for stress evenness,sedimentation adjustment,increase of stability and loading capacity of fundus
Dimensions and Delivery
The polyester geogrids shall be delivered to the jobsite in roll form with each roll individually identified and nominally measuring 2.0 to 6.0 meters in width and 100 meters in length.
