Teflon Extruder
- pplication:
This type machine is used for making teflon cable.
2-Main feature:
It's Suitable for FEP (gather the whole fluorine B propylene , also called F46), FPA and ETFE (also called 40) fluorplastic production.
3-Parameters:
|
Type |
SY-40 |
SY-45 |
SY-50 |
SY-65 |
|
Corediameter(mm) |
1-3 |
2-8 |
||
|
Screwlength/diameter |
25:1 |
25:1 |
25:1 |
25:1 |
|
Temperaturecontrol |
4+2 |
|||
|
Heatingpower(kw) |
15 |
18 |
18 |
25 |
|
Mainservomotor(kw) |
11 |
11 |
11 |
25 |
|
Tractionservomotor(kw) |
||||
|
Maxextrusioncapacity(kg/h) |
30 |
35 |
45 |
100 |
|
Maxlinespeed(m/min) |
180 |
180 |
180 |
180 |
|
Pay-off |
Shaftactivepay-off 300-500 |
|||
|
Take-up |
400-630shafttake-upmachine withmotor; 3kw+inverter+screw traversing |
|||
|
Size(m) |
20×1.5×2.1 |
20×1.6×2.1 |
20×1.7×2.1 |
20×2.5×2.1 |
|
Weight(T) |
7 |
8 |
||
4-Advantages:
1)Screw cylinder: New steel No.3 GH113 (with the American GDA material) able to bear the high temperature corrosion.
2)Head: New steel No.3 GH113 material special-purpose adjustable or automatic type.
3)Heating up system use high-temperature resistance copper alloy.
4)Quality control:Outer diameter detection feedback device to control product outside diameter, concentricity etc.
