Mechanic DC-2405 intelligent 24V 5A digital power supply temperature-controlled dual-channel DC output, with fast charging protocol output, supports PD3.1, QC3.0, USB-A charging port, 5 groups of output channels, suitable for mobile /tablet/electronic motherboard repair.
Features:
1. Mechanic DC-2405 intelligent temperature control dual-channel DC digital power supply Dual-channel DC output, peak output 24V/5A, two groups of DC output channels can be set independently of the voltage output number.
2. 5 groups of output channels can be switched by key to display the current real-time value.
3. Fast charging protocol output, equipped with three charging protocol ports, supports PD3.1, QC3.0, USB-A charging protocol output.
4. Intelligent temp-control heat dissipation, adopt full-metal body for conduction cooling, then through the temperature detection to open the fan for intelligent temperature control cooling to avoid prolonged high-power operation, resulting in high internal temperature.
5. Built-in over-current, over-voltage, short-circuit, and other multiple protection mechanisms, to ensure that the output can be cut off in time under abnormal conditions, to protect the equipment and load from damage.
6. Equipped with a high-precision adjusting knob encoder, it allows you to finely adjust the output voltage and current according to your needs, easy to operate and precisely control.
Specification:
Model: Mechanic DC-2405 DC Numerical Control Power Supply.
Voltage: AC110V-220V.
Fuse: 3A(AC 220V).
Output voltage: DC 0~24V.
Maximum output current: 5A.
Maximum instantaneous current: 7A(1 second).
Maximum output power: 120W.
Current display accuracy: ±1mA.
Voltage adjustment step: 10mV.
Size: 137*118*72mm.
Net Weight: 795g.
Gross Weight: 1377G.
Package includes:
1 x Power Supply.
1 x Output clip cable-red.
1 x Output clip cable-black.
1 x Equipment Power Cable.
1 x Specification.
