Automatic dry cleaning tester
Instrument Purpose
The YG-6 Fully Automatic Dry Cleaning Tester is used to evaluate the physical properties of wool, fur, cotton-linen, worsted, and synthetic fabrics, as well as garments, after dry cleaning. It measures changes in appearance color, dimensional stability, and peel strength.
Compliance Standards
GB/T 19981.2, GB/T 11401.1, ISO 3175.1, FZ/T 01013, FZ/T 80007.3, FZ/T 01083
Technical Parameters
| Working Mode | Microcomputer-controlled; automatic testing; LCD Chinese display; alarm sound prompt |
| Rated Capacity | 8kg |
| Drum Specifications | φ715×340mm |
| Liquid Tank Capacity | 90L (1st tank), 80L (2nd tank), 98L (3rd tank) |
| Distillation Tank Capacity | 72L |
| Washing Speed | 45r/min |
| Dehydration Speed | 420r/min |
| Drying Time | 1–99 minutes |
| Odor Exhaustion Time | 1–99 minutes |
| Drying Temperature | Room temperature to 60±3°C |
| Power | AC380V, 50Hz, 5KW, three-phase four-wire system |
