Horizontal Vertical Combustion Tester
Introduction
Horizontal and vertical combustion testeris to simulate the early situation of a fire around the electrical environment .By simulating the actual situation, the tester can assess the material fire risk, product resistance to ignition and safety characteristic of no flame spread . Horizontal and vertical combustibility tester can test material’s burning performance, burning rate, flame spread, combustion strength and product flame resistance properties.
Applications
Horizontal and vertical combustion tester is mainly used for measuring the burning performance of plastic, rubber or film at a predetermined fire source, to determine its fire resistance rating. It can be applied not only for the research, production and quality control departments of lighting, low-voltage electrical appliances, household appliances, electrical machine, tools, instruments as well as electrical connections and other electrical and electronic plastic or rubber products and component parts, but also for the type approval of insulation, plastic , fire blocking material or other solid combustible materials industry.
Features
◆The ultra - large transparent observation window makes it easy to observe the burning state of the specimen;
◆Humanized design of the door opening way. It is an easy way to touch the sample and burner;
◆PLC touch screen control is easy to set parameters;
◆Different test methods modular is easy to operate;
Standards
UL94 Test for flammability of plastic materials for parts in devices and appliances
ISO 1210 Plastics -- Determination of the burning behaviour of horizontal and vertical specimen
GB/T2408-2008/IEC:1999 Plastics-Determination of burning characteristics- Horizontal and vertical test
GB/T 5169.16-2008/IEC :2003/ASTM D635 Fire hazard testing for electric and electronic products. Part 16:Test flames. 50W horizontal and vertical flame test methods
GB/T 8332-2008/ISO 9772-2001/ASTM D 4986 Test method for flammability of cellular plastic-Horizonal burning method
ASTM D4804 /ISO 9773 Standard test method for determining the flammability characteristics of non-rigid solid plastics
Accessories
Configuration
Base unit
F241G Calibration copper
F241G01 Cotton tray
233G02 HB Support Fixture
Optional parts
F241H Foam Support Fixture
F241G03 Support-Gauze
F241G04 Burner Wing Tip meets the requirements of ASTM D4986 standard
F241G05 Specimen Mandrel Form
Technical Parameters
| Items |
Parameters |
| Inter Size |
850mm×600mm×1000mm |
| Vent (above) |
Φ135mm×85mm |
| Burning angle |
45 °，90 ° （0 °） Adjustable |
| The specimen holder can be moved horizontally vertically |
| Flame time |
5s, 10s, 30s, 60s optional |
| Combustion timer |
Timer (accurate to 0.1s) |
| Burner |
Length 100 ±10 mm, Inner diameter 9.5 ±mm 0.3, ASTM D 5025 |
| Outline size |
1200mm * 620mm * 1300mm |
| Weight |
90kg |
| Power supply |
220V, 50Hz |
