Horizontal paper tensile strength testing machine

•

Product Introduction:

G103C horizontal tensile strength tester adopts paper tensile strength software, which is a paper resistance tester for measuring the tensile strength, tensile strength and tensile energy absorption of paper and cardboard, paper towels, wipes and other similar thin sheet materials. Suitable for all kinds of paper, electrolytic aluminum, release paper, release film, isolation paper, Glassine silicone oil paper, protective film, transfer film, composite film, tape, adhesive and other products (measuring tensile strength, peeling force, tensile strength, peeling strength, elongation, breaking length, tensile energy absorption, tensile index, tensile energy absorption index) high-precision test.

Implementation standards:

ISO 1924 "Determination of tensile strength of paper and board"

GB/T 12914 "Determination of tensile strength of paper and board (constant rate tensile method)"

ISO 1924-2 Paper and board - Determination of tensile strength - Part 2: Constant rate drawing method

Product Advantages:

Measures Key Mechanical Properties: Accurately determines tensile strength, elongation, tensile energy absorption, and other related properties crucial for material performance assessment.

Versatile Material Testing: Applicable to a wide variety of thin, flexible sheet materials, including different types of paper, paperboard components, films, tapes, and adhesives.

Multiple Test Types: Capable of performing both tensile and peel strength tests, offering comprehensive evaluation capabilities.

High Precision and Resolution: Provides high-precision testing with fine resolution for both force and displacement measurements.

Standard Compliant: Designed to meet numerous international and national standards for tensile and related testing of paper and flexible materials.

Controllable Testing Parameters: Allows for precise control over loading speed to comply with standard requirements and specific test methods.

Comprehensive Data Output: Provides various calculated results and index values, facilitating detailed material analysis.

Ergonomic Horizontal Design: The horizontal configuration can make sample loading and testing easier for flexible materials by preventing sagging.

Technical parameters:

Load measurement range: 0.03-30N, 0.05-50N, 0.2-100N, 0.4-200N, 0.5-300N

Force separation rate: 0.001N

Displacement separation rate: 0.001mm

Loading speed: 1-500mm/min(other speed is adjustable)

Sample width: 0-30mm

Travel: 400mm+

Power: 60W

Power supply: 220V 50Hz

Dimensions: 280mm×150mm×800mm (approx.)

Environmental requirements: Temperature 10-35 ℃， humidity 20-80%
