Gantry Vision Measuring Machine

Standard:

ISO9001

Product advantages:

Longmen Automatic image measuring instrument is specially designed for large size measurement, with a maximum stroke of 3000X2000mm, suitable for large stroke measurement in PCB, LCD, sheet metal, aerospace and other industries. It uses the moving bridge structure to bring together the most advanced design concepts in the industry, with the most perfect design and the most stringent production process control to ensure the accuracy and stability of the machine.

Product features:

* Moving bridge structure, large stroke automatic measurement, four-axis CNC control.

* Precision granite machine, high precision, good stability.

* Full mouse, handle type automatic control, easy to use,

* Automatic magnification optical lens, can achieve conversion measurement, programmable 5 ring 8 zone ring surface light source, LED wheel corridor light source,

*ZONSON2D automatic image measurement software,

* Provides a variety of specifications and standard configurations, and can be customized according to requirements.

Parameters:

Instrument measurement accuracy :≤(3+L/200)um

Operation mode: automatic control handle operation

Three-axis control system: Germany Bruker DC precision servo motor drive (with brake)

Grating ruler :SOPIN patch grating ruler, resolution 0.5um

Magnification: Optical magnification 0.7X-4.5X, image magnification 20-180X(customizable)

Imaging system: Hikvision Gigabit network high-speed optical fiber digital camera (no video image card is required for clearer)

Lens: Primis 6.5:1 auto zoom lens

Guide rail: Taiwan HIWIN precision parallel cross rail:

X/Y/Z axis drive: Taiwan HIWIN grinding grade ball screw

Measuring stroke :600*500*180mm, 800*600*180mm, 1000*800*180mm, 1200*1000*180mm, 1500*1000*180mm
